ULTIMA for DYNAMAX
- Edge: Square Lay-In 15/16"
- Dimensions: 23-1/4" x 23-1/4"
- Thickness: 3/4"
- Shape: Rectangle
-
Acoustics:
NRC: 0.75CAC: 35AC: 170 - Fire Performance: Class A
- Light Reflectance: 88%
- Face Profile: 15/16"
REVIT
Product Details
|
Acoustics
Acoustical options available. |
|
|---|---|
|
Sound Absorption (NRC)
A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance. |
0.75 |
|
Sound Blocking (CAC)
A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance. |
35 |
|
Articulation Class (AC)
Product has AC (Articulation Class) 170 or greater. |
170 |
| Fire | |
|
Fire Performance
|
Class A |
|
Light Reflectance
A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only. |
88% |
|
Sag/Humidity Resistance
Ceiling panels maintain humidity and sag resistance. |
HUMIGUARD Plus |
|
Mold/Mildew Resistance
Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface. |
BIOBLOCK |
|
Disinfectability
|
|
|
Fog
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines |
|
|
Special Applications
|
|
|
Material
|
Mineral Fiber |
|---|---|
|
Texture
|
Fine |
|
Shape
|
Rectangle |
|
Weight
|
1.08 lbs/SF |
|
Sq Ft (Sq Ft / Carton)
|
44.04 |
|
Pieces / Carton
|
12 |
|
ASTM Classification
|
Type: A, Form: A2.2, Pattern: E |
|
Installation Method
|
Grid (Suspended) |
|
Made In U.S.A. Of Domestic and Global Content
|
Yes |
|
