LYRA Concealed

Smooth, drywall-like visual with fully-concealed suspension and downward accessibility; Ideal for projects were plenum space is limited. Offers high sound absorption.

Key Features & Performance

Made In U.S.A. Of Domestic and Global Content
Buy America, Build America Act
FASTSIZE
  • DESIGNFLEX options include shapes, made-to-order sizes, and colors available to ship in 3 weeks
  • Large format acoustical panels
  • Downward accessible for minimal plenum height
  • Outstanding acoustical performance for open plan areas, both Noise Reduction and Articulation Class (NRC 0.90, AC up to 190)
  • CLEANASSURE family of products –includes disinfectable panels, suspension systems, and trim
  • Mold- and mildew-resistant surface
  • Smooth, clean, durable finish – Washable, Scratch-resistant, Soil-resistant
  • Energy-saving, high light-reflective finish
  • 30-Year Limited System Warranty against visible sag, mold, and mildew
  • Available with factory-cut holes for USAI® trimless downlight fixture integration
Material
Materials
Fiberglass
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

0.90
Articulation Class (AC)

Product has AC (Articulation Class) 170 or greater.

190
Fire
Fire Performance
Class A (UL)
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

88%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

Inherent
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

HUMIGUARD Plus
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Scratch Resistance

Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test.

Washability

Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.

Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Made In U.S.A. Of Domestic and Global Content
Yes

Get the acoustics right in any space!

Request a complimentary Custom Acoustical Report for your next project and receive a detailed, customized report that will ensure you have the right ceiling to reduce noise, improve speech intelligibility, and/or meet your speech privacy needs.

Direct-to-customer branch of Armstrong.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
71%
Recycled Content
Sustainable Product Search Tool
LEED  •  WELL  •  Living Building Challenge
Recyclable/Extended Producer Responsibility
Recycled Content
Energy Management
Sourcing of Raw Materials
Construction Waste
Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility
Lighting Quality
EPD
Acoustics
Biobased Materials

Configure an Item

Custom color selected. Indicate color when specifying.
Natural color selected. Spec when field painting.
Item Shown: 8433 in White (WH)
Item Shown: Made-to-Order in
Multiple Items Exist
Lead Time: No Requirement
(No Requirement. Details.)
Color: White (WH)
Color shown may vary from actual product.
Panel Size: 24" x 48"
Please contact us for sizes not available online. We can help! Email techline@armstrongceilings.com.
Made-to-Order Sizes
1 ctn minimum, 3 weeks (order to ship)
x
Go
(Enter dimensions by 0.5")
Width
Min: 24
Max: 96
Length
Min: 24
Max: 96
Please specify using 0.5 in. increments
Please specify a number between the minimum and maximum range
Thickness:
7/8"
Edge: Beveled Concealed 15/16
Acoustics: 0.90 NRC / 190 AC

Let us help you select the right acoustics for your project.

  • NRC (Noise Reduction Coefficient)
  • CAC (Ceiling Attenuation Class)
  • STC (Sound Transmission Class)
  • NIC (Noise Isolation Class)
  • AC (Articulation Class)
*View data sheet for mounting methods
Acoustical values are based on size and other selections made.
0.90 NRC / 190 ACNo Data
Available Infill Panels (specified separately)
Acoustical values achieved with infill panel. See data page for details.

Related Accessories

FASTSIZE Program

Factory finished ceiling panels & suspension systems available in one-carton minimums, shipped fast.

Integrated Solutions & Partners

Browse solutions and partners that integrate seamlessly with LYRA Concealed


From Inspiration to Installation


Resources
