Key Features & Performance
- Adjustable Trim Clip (7239) makes AXIOM Classic Trim compatible with WOODWORKS and METALWORKS panels that drop greater than 3/8" below the grid flange
- Crisp-edge detailing and excellent corrosion resistance compared to steel systems
- Dynamic curving capabilities available
- AXIOM trim is part of the SUSTAIN portfolio and meets the most stringent industry sustainability compliance standards today – White and 13 SUSTAIN colors only
- Eight profile heights
- Compatible with Armstrong Suspension Systems and FRAMEALL Drywall Grid
- Finely articulated drywall trim with beaded edge integrates with all trim profiles for pre-engineered drywall transitions
- Colors coordinate with Armstrong ceiling and suspension systems
- Design flexibility for straight and curved applications
- 10-Year Limited warranty, 30-year system warranty
Perimeter Trim
May be wiped following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be sprayed following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
|
Recyclable/Extended Producer Responsibility
|
Recycled Content
|
|
Energy Management
|
Sourcing of Raw Materials
|
|
Construction Waste
|
Material Ingredient Reporting
|
|
Regional Materials
Location Dependent
|
Low emitting/materials
|
|
Design for Flexibility
|
Lighting Quality
|
|
EPD
|
Acoustics
|
|
Biobased Materials
|
Colors & Options
Color shown may vary from actual product.
Colors
- Basalt
- Black
- Blizzard White
- Boxwood
- Charcoal Black
- Coffee
- Feldspar
- Fern
- Fossil
- Grey Stone
- Gun Metal Grey
- Hay
- Honeysuckle
- Ivory
- Ivy
- Light Grey
- Lilac
- Limestone
- Marigold
- Medium Taupe
- Mist
- Mottled Silver Grey
- Oat
- Ocean
- Pacific
- Polar
- Rainstorm
- Riverstone
- Rose
- Sandstone
- Silver Grey
- Silver Satin
- Topaz
- Twilight
- White
- AXIOM Classic in Custom Color
97 AXIOM Classic Products
Sustain = Items included in the SUSTAIN portfolio
| Item # | Description | Drawing | Color | |||
|---|---|---|---|---|---|---|
| Inside Corner | ||||||
AX10ISCPSustain | 10in Axiom Classic Inside Corner Post |  |
| |||
AX10QSISSustain | 10in Axiom Classic Quick Ship Inside Corner |  |
| |||
AX12ISCPSustain | 12in Axiom Classic Inside Corner Post | |
| |||
AX12QSISSustain | 12in Axiom Classic Quick Ship Inside Corner | |
| |||
AX14QSISSustain | 14in Axiom Classic Quick Ship Inside Corner | |
| |||
AX14QSIS3Sustain | 14in Axiom Classic Quick Ship Inside Corner 360 Painted | |
| |||
AX16QSISSustain | 16in Axiom Classic Quick Ship Inside Corner | |
| |||
AX16QSIS3Sustain | 16in Axiom Classic Quick Ship Inside Corner 360 Painted | |
| |||
AX2ISCPSustain | 2in Axiom Classic Inside Corner Post | |
| |||
AX2QSISSustain | 2in Axiom Classic Quick Ship Inside Corner | |
| |||
AX4ISCPSustain | 4in Axiom Classic Inside Corner Post | |
| |||
AX4ISCP3Sustain | 4in Axiom Classic Inside Corner Post - 360 Degree | |
| |||
AX4QSISSustain | 4in Axiom Classic Quick Ship Inside Corner |  |
| |||
AX6ISCPSustain | 6" Axiom Classic Inside Corner Post | |
| |||
AX6QSISSustain | 6in Axiom Classic Quick Ship Inside Corner | |
| |||
AX8ISCPSustain | 8in Axiom Classic Inside Corner Post | |
| |||
AX8QSISSustain | 8in Axiom Classic Quick Ship Inside Corner | |
| |||
AX10WECSustain | Axiom Welded End Cap for 10" Classic |  | ||||
AX12WECSustain | Axiom Welded End Cap for 12" Classic |  | ||||
AX2WECSustain | Axiom Welded End Cap for 2" Classic | |||||
AX4WECSustain | Axiom Welded End Cap for 4" Classic | |||||
AX6WECSustain | Axiom Welded End Cap for 6" Classic | |||||
AX8WECSustain | Axiom Welded End Cap for 8" Classic | |||||
AXDWT8DFSustain | Axiom Drywall Trim |  |
| |||
AX10OSCPSustain | 10in Axiom Classic Outside Corner Post |  |
| |||
AX10QSOSSustain | 10in Axiom Classic Quick Ship Outside Corner | |
| |||
AX12OSCPSustain | 12in Axiom Classic Outside Corner Post | |
| |||
AX12QSOSSustain | 12in Axiom Classic Quick Ship Outside Corner | |
| |||
AX14QSOSSustain | 14in Axiom Classic Quick Ship Outside Corner | |
| |||
AX14QSOS3Sustain | 14in Axiom Classic Quick Ship Outside Corner 360 Painted |
| ||||
AX16QSOSSustain | 16in Axiom Classic Quick Ship Outside Corner | |
| |||
AX16QSOS3Sustain | 16in Axiom Classic Quick Ship Outside Corner 360 Painted | |
| |||
AX2OSCPSustain | 2in Axiom Classic Outside Corner Post | |
| |||
AX2QSOSSustain | 2in Axiom Classic Quick Ship Outside Corner | |
| |||
AX4OSCPSustain | 4in Axiom Classic Outside Corner Post | |
| |||
AX4QSOSSustain | 4in Axiom Classic Quick Ship Outside Corner | |
| |||
AX6OSCPSustain | 6in Axiom Classic Outside Corner Post | |
| |||
AX6QSOSSustain | 6in Quick Ship Outside Corner | |
| |||
AX8OSCPSustain | 8in Axiom Classic Outside Corner Post | |
| |||
AX8QSOSSustain | 8in Axiom Classic Quick Ship Outside Corner | |
| |||
AXPNP34NRSustain | No Pocket, 3/4" Acoustical Flange, No Reveal with Closure Clip | |||||
AX10STRSustain | 10in Axiom Classic Straight | |
| |||
AX10STR3Sustain | 10in Axiom Classic Straight 360 Painted | |
| |||
AX12STRSustain | 12in Axiom Classic Straight | |
| |||
AX12STR3Sustain | 12in Axiom Classic Straight 360 Painted | |
| |||
AX14STRSustain | 14in Axiom Classic Straight |  |
| |||
AX14STR3Sustain | 14in Axiom Classic 360 Painted | |
| |||
AX16STRSustain | 16in Axiom Classic Straight |  |
| |||
AX16STR3Sustain | 16in Axiom Classic Straight 360 Painted | |
| |||
AX2STRSustain | 2in Axiom Classic Straight |  |
| |||
AX2STR3Sustain | 2in Axiom Classic Straight 360 Painted | |
| |||
AX3STR | 3in Axiom Classic Straight |
| ||||
AX3STR3 | 3in Axiom Classic Straight - 360 Painted |
| ||||
AX4STRSustain | 4in Axiom Classic Straight |  |
| |||
AX4STR3Sustain | 4in Axiom Classic Straight 360 Painted | |
| |||
AX6STRSustain | 6in Axiom Classic Straight |  |
| |||
AX6STR3Sustain | 6in Axiom Classic Straight 360 Painted | |
| |||
AX8STRSustain | 8in Axiom Classic Straight |  |
| |||
AX8STR3Sustain | 8in Axiom Classic Straight 360 Painted | |
| |||
AXBTASTR | Axiom Bottom Trim for Acoustibuilt- Straight |  |
| |||
AX10CURSustain | 10in Axiom Classic Curved |  |
| |||
AX10CUR3Sustain | 10in Axiom Classic Curved 360 Painted | |
| |||
AX12CURSustain | 12in Axiom Classic Curved | |
| |||
AX12CUR3Sustain | 12in Axiom Classic Curved 360 Painted | |
| |||
AX14CUR | 14" Classic Curved - White |
| ||||
AX14CUR3 | 14" Curved Axiom |
| ||||
AX16CUR | 16" Classic Curved |
| ||||
AX16CUR3 | 16" Curved Axiom - Painted all sides |
| ||||
AX2CURSustain | 2in Axiom Classic Curved |  |
| |||
AX2CUR3Sustain | 2in Axiom Classic Curved 360 Painted | |
| |||
AX3CUR | 3" Curved Axiom |
| ||||
AX3CUR3 | 3" Curved Axiom - 360 Painted |
| ||||
AX4CURSustain | 4in Axiom Classic Curved | |
| |||
AX4CUR3Sustain | 4in Axiom Classic Curved 360 Painted | |
| |||
AX6CURSustain | 6in Axiom Classic Curved |  |
| |||
AX6CUR3Sustain | 6in Axiom Classic Curved 360 Painted | |
| |||
AX8CURSustain | 8in Axiom Classic Curved | |
| |||
AX8CUR3Sustain | 8in Axiom Classic Curved 360 Painted | |
| |||
AXBTACUR | Axiom Bottom Trim for Acoustibuilt- Curved |  |
| |||
AX10DCCSustain | 10in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX10DCC3Sustain | 10in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX12DCCSustain | 12in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX12DCC3Sustain | 12in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX14DCCSustain | 14in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX14DCC3Sustain | 14in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX16DCCSustain | 16in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX16DCC3Sustain | 16in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX2DCCSustain | 2in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX2DCC3Sustain | 2in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX3DCCSustain | 3in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX3DCC3Sustain | 3in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX4DCCSustain | 4in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX4DCC3Sustain | 4in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX6DCCSustain | 6in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX6DCC3Sustain | 6in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
AX8DCCSustain | 8in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) | |
| |||
AX8DCC3Sustain | 8in Axiom Classic Dynamic Curved Corners (STR-CUR-STR) 360 Painted | |
| |||
Related Accessories
Allows AXIOM trim to be positioned up to 3-3/4" below the grid face to accommodate deeper panel offsets (best aesthetic with AXIOM ≥ 6" tall).
Provides positive mechanical lock and screw-fastened connection to suspension members that intersect below the trim channel.
Provides positive mechanical lock and screw-fastened connection to suspension members that intersect below the trim channel.
Joins 2 ACT ceiling systems on seismic DEF installations (can also be used to join 2 different ceiling systems).
Galvanized sheet steel formed to fit into special trim channel bosses. Provides positive mechanical lock with factory-installed screw. Screw-fastened connection to suspension members that intersect the trim channel
